ACROTEC INTERNATIONAL Co., Ltd.
| Item No |
: | |
| PCB size | : | W20*D20～W550*D500 mm |
| Workable area | : | W550*500 mm |
| PCB thickness | : | 0.5～4mm |
| Applicable BGA | : | 1*1～80*80mm |
| Working table adjustment | : | ±10mm Forward/backward, ±10mm Left/right |
| PCB locating way | : | Jig |
| Placement precision | : | ±0.01mm |
| Min. pitch of BGA ball | : | 0.15mm |
| Gross power | : | 5600W |
| Bottom IR preheat | : | 3600W |
| Top heater | : | 800W |
| Bottom heater | : | 1200W |
| Max BGA weight | : | 80g |
| Power supply | : | Single-phase 220V、50/60Hz |
| Machine dimension | : | L720*W705*H860mm |
| Weight | : | Appox.80kgs |
