ACROTEC INTERNATIONAL Co., Ltd.
| Item No |
: | |
| Size |
: | |
| Packing | : | |
| PCB dimension | : | W20*D20～W550*D500mm |
| PCB thickness | : | 0.5～4mm |
| Working table adjustment | : | ±120mm Forward/backward, ±80mm Left/right |
| Temperature controlt | : | K-type Thermocouple, Close Cycle Controlled |
| PCB locating way | : | Outer |
| lower hot air heater | : | 800W |
| upper hot ait heater | : | 1200w |
| Bottom preheat far infrared | : | 3600W |
| Power supply | : | Single-phase 220v,50/60Hz |
| BGA dimension | : | 1*1~80*80mm |
| Min pitch of BGA ball | : | 0.15mm |
| Placement precision | : | ±0.01mm |
| Max BGA weight | : | 80g |
| Machine dimension | : | L850*W750*H630 |
